| VMZ Solar | TECHNICAL DATA |
| Parameter | Value |
| Type | Awning blind with side guide rails |
| Use | Vertical windows and doors made of PVC, aluminium or wood (balcony, terrace); external installation |
| Control | Automatic (depending on insolation), semi-automatic (self-activating unrolling, rolling up via remote control) or remote control (remote control sold separately) |
| Power supply | 15VDC solar battery pack built into the cassette, charged by the solar panel |
| Dimensions (width A x height B) | A 645-3000 x B 400-3500 mm; A 3001-4000 x B 400-2700 mm (made to measure) |
| Fabric relative open area | 10%, 1%, 4%, 0% (0% not for manual VMZ) |
| Standard aluminium profile colours | RAL 7022, RAL 8003, RAL 9005, RAL 9010; any RAL colour on request |
| Cassette | Type A (oval), Type B (rectangular), Type C (round; Solar version then uses an external solar panel with 3 m cable); height 85 mm or 100 mm; single or combined guide rails |
| Solar panel | Battery pack 15VDC built into the cassette; the panel must have direct sunlight (south, east or west facing roofs recommended) |
| Colors | Fabric 089 (10% relative open area), Fabric 090 (10% relative open area), Fabric 091 (10% relative open area), Fabric 092 (1% relative open area), Fabric 093 (1% relative open area), Fabric 701 (4% relative open area), Fabric 702 (4% relative open area), Fabric 703 (4% relative open area), Fabric 704 (4% relative open area), Fabric 705 (4% relative open area), Fabric 706 (4% relative open area), Fabric 707 (4% relative open area), Fabric 708 (4% relative open area), Fabric 709 (4% relative open area), Fabric 710 (4% relative open area), Fabric 711 (4% relative open area), Fabric 712 (4% relative open area), Fabric 713 (4% relative open area), Fabric 714 (4% relative open area), Fabric 715 (4% relative open area), Fabric 720 (0% relative open area), Fabric 721 (0% relative open area), Fabric 722 (0% relative open area), Fabric 723 (0% relative open area), Aluminium profile RAL 7022, grey (standard), Aluminium profile RAL 8003, brown (standard), Aluminium profile RAL 9005, black (standard), Aluminium profile RAL 9010, white (standard) |
