Specific data
| Category | Value / Description |
|---|---|
| Characteristic values | |
| Equilibrium moisture (65% rel.) | ≈ 71 °C (at 20 °C and 65 % RH, according to DIN EN ISO 12570) |
| Alkalinity (pH value) | Approximately 12 |
| Miratimet | |
| Building material class | EN 13501-1 — Non-combustible, A1 |
| Fire resistance class | I 90 and E 90 (1) |
| Panel parameters and formats | |
| Panel thickness | 52.5 mm |
| Surface weight per m² (with moisture 5%) | 47 kg/m² |
| Format panels | 1 250 x 625 mm |
| Other forms | Thickness, formats, and cuts as requested |
| Dimensional tolerances | |
| Width | ± 1 mm |
| Thickness | ± 2 mm |
| Maximum allowed traffic load | |
| 60 cm | 12.5 kN/m² |
| 80 centimeters | 7.0 kN/m² |
| 95 cm | 5.0 kN/m² |
| 100 cm | 4.5 kN/m² |
| 125 cm | 2.8 kN/m² |
| Maximum permissible load (proof load test) | |
| Scope of support | 100 cm |
| Jump height | 82 cm |
| Subject of the test | 100 kg |
| Investigation Report | MFPA Leipzig, UB III/B-06-014 |
| (1) Fire resistance values depend on the construction system and the installation details. | |
