Characteristics
| Category | Value / Description |
|---|---|
| Characteristics | |
| Apparent density ρk (dry) | 680 – 800 kg/m³ |
| Bending force (EN 12467 ±10%) | Greater than or equal to 1.5 N/mm² |
| Extension / Retraction (change RH 30%, 20 °C, EN 318) | ≈ 0.1% |
| Equilibrium humidity (651 TP3T RH, 20 °C, EN ISO 12570) | ≈ 5% |
| Alkalinity (pH value) | Approximately 10 |
| Modulus of elasticity in bending (EN 12467 ±10%) | ≈ 2,000 N/mm² |
| Reference value | For a 20 mm thick board |
| Miratimet | |
| European technical approval | ETA-17/0170 |
| Building material class (DIN EN 13501-1) | You're burning, A1 |
| Application category (ETAG 018-1) | Z1, Z2, Y, X |
| Classification of building elements | International Engineering Structure |
| Fire test (international curves, ZTV/EBA concrete) | RWS120, RWS180, HCM120, ISO240 |
| Dimensional tolerances | |
| Length and width | ± 1 mm |
| Diagonal difference | Less than or equal to 2 mm |
| Thickness | ± 1 mm |
| Board dimensions | |
| Board size (mm) | 2600 x 625 mm |
| Available thicknesses (mm) | 20 / 25 / 30 / 35 / 40 / 60 |
