Characteristics
| Category | Value / Description |
|---|---|
| Characteristics | |
| Apparent density ρk (dry) | ≈ 690 – 980 kg/m³ |
| Bending force (EN 12467 ±10%) | Approximately 3.5 N/mm² |
| Thermal conductivity λR (DIN 12667) | ≈ 0.175 W/mK |
| Extension/Retraction (change RH 30%, 20°C, EN 318) | ≈ 0.151 TPD |
| Equilibrium humidity (651 TP3T RH, 20 °C, EN ISO 12570) | ≈ 7% |
| Compressive strength (EN 789) | ≈ 9 N/mm² |
| Alkalinity (pH value) | Approximately 12 |
| Modulus of elasticity in bending (EN 12467 ±10%) | ≈ 2,000 N/mm² |
| Value for 20mm board | According to the manufacturer's specification |
| Miratimet | |
| Building material class (DIN EN 13501-1) | You're burning, A1 |
| Classification of building elements | International Engineering Structure |
| Fire testing (international curves, ZTV/EBA) | RWS120, RWS180, HC180, HCM120, HCM180 |
| Dimensional tolerances | |
| Length and width | ± 1 mm |
| Diagonal difference | Less than or equal to 2 mm |
| Thickness | ± 1 mm |
| Available sizes | |
| Tile size (mm) | 2600 x 625 mm |
| Available thicknesses (mm) | 10 / 15 / 20 / 25 / 30 / 35 / 40 / 50 / 60 |
